Tesla series is at the pinnacle of where lighting innovation meets energy efficiency. A high performance serviceable integrated LED with a state of the art light engine delivers incredible maintenance-free optics and performance ideal for high-end residential and commercial applications. With a wide variety of solid die-cast trims in a multitude of handsome plated or powder coated finishes, the Tesla collection is sure to enhance style and appeal in any space. Tesla PRO provides up to 60% higher lumen output over the standard Tesla collection for when more lighting is required such as in tall ceiling applications. The trim and LED engine are manufactured as a single unit with endless amounts of specifications including shape and finish of trim, adjustability, color temperature, and beam distribution to create the perfect combinations of form, factor, and function. The housing is sold separately and is available for both New Construction and Remodel applications with IC and airtight rating options.
- Made of Aluminum
- Shade/Glass Color: Borosilicate Clear Diffuser
- Shade/Glass Made of Borosilicate
- (1) 21.5W LED Bulb
- Bulb Included
- Bulb Average Hours: 50000
- 85 CRI Version Bulb Lumens: 3000K-516/3500K-522
- 90 CRI Version Bulb Lumens: 2700K-402/3000K-366
- Bulb Beam Spread: 15
- Bulb Shape: LED Module
- Voltage: 120-240-277 Universal
- Dimmable: Yes
- Tesla 3.5" housings can be used with 3.5" Tesla and Tesla PRO series trims. Trim and LED Light engine are manufactured together, no lamp required. Housing is sold separately.
- Wide variety of solid die-cast trims in a multitude of handsome plated or powder coated finishes. Use HR-3LED-R18D-A, HR-3LED-R22D (remodel) or HR-3LED-H18D1-ICA, (new construction) housings.
- Trim and Light Engine are built to specification including shape and finish of trim, adjustability, color temperature, and beam distribution to create the perfect combinations of form, factor, and function.
- Smooth and continuous ELV and 0-10V dimming options down to 5%. Superior cut-off angle for glare control.
- High powered replaceable LED module: Available in 2700K, 3000K, 3500K, or 4000K Color Temp, up to 90CRI, 90,000 Rated Hours.
- Standards: UL & cUL Listed damp locations. (ET109 & 209 & 818 Trims are wet location Rated). 90CRI model is CEC Title 24 Compliant.
- Plugin
- Part of the Tesla Collection
- Style: Functional
- For Use in Interior Locations
- Safety Rating: UL, cUL
- Warranty Info: 5 Years Functional, 2 Years Finish
Overall Dimensions: 5.25"(L) x 5.25"(W) x 5.63"(H) x 5.25"(Dia)
Backplate/Canopy Dimensions: Trim Size: 3.5"(D) x Trim Size: 5.25"(W) x Cutout: 4.63"(H)
Item Weight: 5.52 lbs.
