120V step and wall lights by WAC Lighting are offered in a variety of styles and can be installed onto a standard 2in x 4in electrical junction box. These luminaires offer enhanced energy efficient functionality and optimized light output to adequately illuminate stairs, walls and walkways with little or no glare and are perfect for indoor or outdoor applications. Available in 3000K warm white, 2700K warm, amber warm, blue, and red LED color temperatures - order accordingly. Factory sealed and water tight with an IP66 rating for protection against high-pressure water jets and outdoor elements. Casted using a special k-alloy aluminum that is engineered to withstand the most challenging environments over time. Stainless steel (-SS) or solid brass coated in bronze (-BBR) finishes are available for enhanced protection against corrosive elements and is recommended for use in coastal or marine environments.
- Finish: Solid Brass Coated in Bronze or Graphite
- Made of Brass
- Shade Finish: Frosted
- Shade Made of Glass
- Shade/Glass Description: Frosted Glass Lens
- Style: Contemporary
- (1) 3.8W LED Bulb(s)
- Bulbs Included
- Bulb Color Temp: 2700
- Bulb Average Hours: 50000
- Bulb Lumens: 100
- Bulb Delivered Lumens: 68
- Bulb Beam Spread: 37
- Bulb Shape: LED
- Bulb CRI: 90
- Voltage: 120
- Bulb Base: LED Module - ACLED Module
- Step Light, Replaceable LED, Interchangeable Lens of Choice (Clear, Amber, Red, Blue), Junction Box Mounting Bracket, Hardware
- 120V step and wall lights by WAC Lighting are offered in a variety of styles and can be installed onto a standard 2in x 4in electrical junction box. These luminaires offer enhanced energy efficient functionality and optimized light output to adequately illuminate stairs, walls and walkways with little or no glare and are perfect for indoor or outdoor applications.
- Factory sealed water tight and IP66 rated for protection against high-pressure water jets and outdoor elements.
- Casted using a special k-alloy aluminum that is engineered to withstand the most challenging environments over time. Stainless steel (-SS) or solid brass coated in bronze (-BBR) finishes are available for enhanced protection against corrosive elements and is recommended for use in coastal or marine environments.
- Available in 3000K warm white, 2700K warm, amber warm, blue, and red LED color temperatures - order accordingly. Amber color temperature is turtle friendly. Special daylight photocell sensor option is available that turns the steplight on at dusk and off at dawn automatically, SKU # WL-LED102 and WL-LED202. Brushed Nickel finishes are only for interior use.
- High Powered LED, Input: 9-15V AC, Power: 2W (3VA), Brightness: Up to 68Lm, CRI: 90, Rated Hours: 60,000. Smooth and continuous dimming to 10% with a Magnetic Low Voltage Dimmer.
- Standards: UL & cUL 1598 and IP66 Rated for Wet Locations (See Specification Sheet for complete details). Fits into 2” × 4” J-Box with minimum inside dimensions of 3"L × 2"W × 2"D.
- Dimmable: ELV
- ADA: Yes
- Interior/Exterior: Interior/Exterior
- Hardwired/Portable: Hardwired
- Length of Electrical Wire: 6"
- Safety Rating: UL/CUL/IP66 Listed
- For Use in Wet Locations
- Warranty Info: 5 Years Functional, Lifetime Warranty on Finish
Overall Dimensions: 1.5"(L) x 3"(W) x 3"(H)
Backplate Dimensions: 1.75"(D) x 5"(W) x 3.13"(H)
Item Weight: 0.91 lbs.
