Layne is a rectilinear juxtaposition of modern minimal lines with classic architectural references. This eight inch tall LED wall luminaire is offered in a brushed nickel or bold black finish and is ADA Compliant. Layne is ideal for public spaces such as hotel corridors, office buildings and other hospitality and commercial settings or fine homes. This LED luminaire provides advanced driverless ACLED technology featuring a superior quality light with an outstanding 90 color rendering index and a long 50,000 hour rated LED life. Order with your desired color temperature and use the built-in color temperature adjustability switch to adjust from warm white 2700K, to soft white 3000K, or bright white 3500K. This LED luminaire is ETL and cETL listed for damp locations and operates on a 120 volt system, meeting stringent California Title 24 energy efficient standards. Dims down nicely using an electronic low voltage or TRIAC dimming system. Dual functional and highlighted with a clean modern aesthetic.
- Part of the Layne Collection
- Finish: Black or Brushed Nickel
- Made of Aluminum
- Shade Color: Clear
- Shade Made of Glass
- Shade Description: Glass Diffuser
- Style: Contemporary
- (2) 5.5W Integrated LED Bulbs
- Bulbs Included
- Bulb Base: LED Module - ACLED Module
- Bulb Color Temp: 2700-3000-3500
- Bulb Average Hours: 54000
- Bulb Lumens: 621
- Bulb Beam Spread: Flood
- Bulb Shape: LED Module
- Bulb CRI: 90
- Delivered Lumens: 229
- Voltage: 120
- Provides and abundance of both up and down lighting. The body is constructed out of aluminum with glass diffusers.
- Layne is ADA rated and damp location listed - can be used indoor or covered outdoor areas. Can be mounted up or down to suit your application.
- AC LED technology - no driver or transformer required. Easily fits on a pancake junction box. Tri-CCT technology features a switch inside the canopy that is accessible during installation and allows you to toggle color temperatures between 2700K Warm - 3000K Warm White - 3500K White to find and set the perfect color temperature for your space. This fixture is factory pre-set to the CCT ordered and can be modified in the field with the flick of a switch.
- Smooth and continuous dimming with electronic low voltage ELV or TRIAC dimmer options.
- High Powered Replaceable LED Module CRI: 90, Rated Hours: 54000, Color Temp Adjustability: 2700K-3000K-3500K
- Standards: ETL & cETL UL 1598 listed with IP44 rating for Damp Locations. CEC Title 24 compliant.
- Dimmable: ELV, TRIAC
- ADA: WS-81208_SP.pdf
- Interior/Exterior: Interior or Covered Exterior
- Hardwired or Portable: Hardwired
- Safety Rating: ETL, cETL, IP44
- For Use in Damp Locations
- Warranty Info: 5 Years Functional, 2 Years Finish
Overall Dimensions: 5.25"(L) x 1.75"(W) x 7.5"(H)
Back plate/Canopy Dimensions: 3.75"(L) x 4.5"(W) x 0.5"(D)
Item Weight: 4.39 lbs.
Manufacturer Part Number: WS-81208-27-BK
Ships from our warehouse in 1-4 Business Days
