A 20-watt LED wall pack for commercial exterior security lighting, with selectable color temperature and a durable white die-cast aluminum body.
The Nuvo 65-749 LED Small Wall Pack combines energy efficiency with versatility. Its CCT selectable feature lets you choose between warm (3000K), cool (4000K), or natural (5000K) white light to suit your environment. The built-in photocell sensor automatically turns the light on at dusk and off at dawn, while the 100-degree beam spread provides wide coverage. Rated IP65 for wet locations, this fixture is built to withstand the elements.
Best for
- Commercial building exteriors, such as entryways, loading docks, and parking areas
- Residential security lighting for garages, patios, and backyards
- Wet locations exposed to rain or snow, thanks to IP65 rating
- Areas where dusk-to-dawn automatic operation is desired
- Retrofit or new construction with 120V-277V electrical systems
Not ideal for
- Indoor accent or decorative lighting – this is a utilitarian security fixture
- Spaces requiring a narrow beam or spot lighting – the 100° beam is wide
- Applications where a replaceable bulb is needed – the LED is integrated and non-replaceable
How bright is it?
20 watts of LED output – approximately 2000-2400 lumens depending on color temperature setting. This is comparable to a 150W incandescent floodlight, providing ample illumination for security and general area lighting.
Light color and feel
Selectable CCT: 3000K warm white (soft, inviting), 4000K cool white (bright, neutral), or 5000K daylight (crisp, blue-white). The 0-10V dimming capability allows fine-tuning brightness. CRI is not specified but typical for commercial LED wall packs.
Sizing and fit
Compact dimensions: 3.09 in deep x 5.81 in wide x 8.59 in tall. Suitable for wall mounting on most commercial and residential structures. The die-cast aluminum body is lightweight at 1.98 lbs.
Specifications
- Finish: White
- Style: Utility
- Voltage: 120V-277V
- CCT Selectable
- 0-10V Dimmable
- Maintenance free - no bulb to change
- Die-cast aluminum body
- IP65, Wet rated for outdoor use
- UV Stabilized Powder Coated Finish
- ADA: Yes
- Assembly Required: Yes
- Dimmable: True
- Replaceable Light Source: No
- Overall Dimensions: 3.09"(L) x 5.81"(W) x 8.59"(H)
- Item Weight: 1.98 lbs.
Frequently asked
Is the bulb included? The LED is integrated and non-replaceable – no bulb to change.
Is it dimmable, and what dimmer should I use? Yes, it is 0-10V dimmable. Use a compatible 0-10V dimmer (not a standard TRIAC dimmer).
Can I install this in a bathroom or outdoors? Yes, it is IP65 wet-rated, suitable for outdoor use in rain or snow. Not intended for indoor decorative use.
What's the warranty? Warranty information not specified by manufacturer.
How do I select the color temperature? A switch inside the fixture allows you to choose 3000K, 4000K, or 5000K before installation.
