A 20-watt CCT-selectable LED wall pack for outdoor entryways, multi-unit housing, and light commercial security lighting, finished in white with a UV-stabilized powder coat.
This compact wall pack from Nuvo Lighting delivers superior light output in a small, maintenance-free fixture. The integrated CCT selection switch lets you choose between 3000K, 4000K, and 5000K at installation, while the bypassable photocell enables dusk-to-dawn operation. With an IP65 wet location rating and 2.5KV surge protection, it's built to withstand harsh outdoor conditions.
Best for
- Outdoor entryways and doorways, mounted at 6-8 ft for security and visibility
- Multi-unit housing and apartment building exteriors, where consistent, low-maintenance lighting is needed
- Light commercial applications such as loading docks, parking areas, and walkways
- Landscaping and perimeter lighting, with the photocell enabling automatic operation
- Covered patios and eaves, thanks to the IP65 wet location rating
Not ideal for
- Indoor residential accent lighting - this is a utilitarian outdoor fixture designed for security and area illumination
- Spaces requiring a warm, decorative aesthetic - the modern white housing is functional rather than ornamental
- Areas where 0-10V dimming is not supported - dimming requires compatible controls
How bright is it?
This 20-watt LED fixture provides approximately 2000 lumens (exact output varies by CCT setting) - comparable to a 150W incandescent bulb. Bright enough to illuminate entryways, walkways, and small outdoor areas effectively, but not intended as a primary floodlight for large parking lots.
Light color and feel
Choose your color temperature at installation: 3000K warm white for a cozy, inviting glow; 4000K neutral white for a clean, commercial look; or 5000K daylight for maximum visibility and security. The fixture is 0-10V dimmable, allowing you to adjust brightness as needed. CRI is not specified but typical for commercial LED fixtures.
Sizing and fit
Dimensions: 8.7 in diameter x 3.4 in depth. This compact wall pack fits easily on standard wall surfaces and is ideal for mounting heights of 6-10 ft. The fixture weighs 2.42 lbs and requires assembly (mounting hardware included).
Specifications
- Finish: White
- Style: Modern Contemporary
- Voltage: 120V-277V
- DLC Premium
- Integrated Bypassable Photocell
- CCT Selectable (3000K/4000K/5000K)
- UV Stabilized Powder Coated Finish
- IP65 rated
- 2.5KV Surge Protection
- 0-10V Dimmable
- Integrated LED
- Dimmable: True
- ADA: Yes
- Sensor: Yes - Bypassable
- Assembly Required: Yes
- Overall Dimensions: 3.4"(L) x 8.7"(W) x 8.7"(H)
- Item Weight: 2.42 lbs.
Frequently asked
Is the bulb included? Yes, the LED is integrated and non-replaceable.
Is it dimmable, and what dimmer should I use? Yes, it is 0-10V dimmable. Use a compatible 0-10V dimmer (not standard TRIAC).
Can I install this in a bathroom or outdoors? Yes, it is IP65 rated for wet locations, suitable for outdoor use and bathrooms with direct water exposure.
What's the warranty? Warranty information not specified by manufacturer.
How do I select the color temperature? A CCT selection switch inside the fixture allows you to choose 3000K, 4000K, or 5000K at installation.
