A 48-inch LED backlit flat panel with emergency battery backup, ideal for offices, retail, and commercial spaces needing reliable, energy-efficient lighting.
The SATCO|NUVO LED Backlit 1x4 Flat Panel features ColorQuick and PowerQuick technologies, allowing you to select from three wattages (20W/30W/40W) and three CCT options (3500K/4000K/5000K) at installation. With a flicker-free driver and even light distribution, it provides comfortable, long-term task lighting. The integrated emergency battery backup delivers 90 minutes of light at 8W/1000 lumens, ensuring safety during power outages.
Best for
- Office spaces with drop ceilings, providing uniform ambient light for workstations and meeting rooms
- Retail environments requiring adjustable color temperature to highlight merchandise
- Educational facilities like classrooms and hallways needing energy-efficient, long-lasting lighting
- Hospitality settings such as lobbies and corridors where dimmable, flicker-free light enhances comfort
- Commercial buildings requiring emergency lighting compliance with 90-minute battery backup
Not ideal for
- Residential rooms with low ceilings under 8 ft - the 3-inch depth may feel bulky
- Outdoor or wet locations - rated for damp locations only, not direct rain exposure
- Spaces needing decorative or warm ambient light - this is a utility-grade fixture with selectable cool to neutral white
How bright is it?
Selectable from 2200 to 4600 lumens depending on wattage setting. At 40W/4600 lumens, it's comparable to a 300W incandescent, suitable as a primary light source for rooms up to 200 sq ft. At 20W/2200 lumens, it's similar to a 150W incandescent, ideal for smaller areas or task lighting.
Light color and feel
Selectable CCT: 3500K (warm white, cozy), 4000K (neutral white, crisp), 5000K (daylight, energizing). The flicker-free driver reduces eye strain, making it suitable for long-term use. Dimmable via 0-10V dimmer for adjustable ambiance.
Sizing and fit
Dimensions: 47.72" L x 11.84" W x 3.09" H. Designed for standard 1x4 ft drop ceiling grids. The low profile (3.09") works in ceilings as low as 8 ft. Weight: 4.98 lbs.
Specifications
- Finish: White
- Style: Utility
- Wattage: 20W/30W/40W Selectable
- Bulb Average Hours: 50000
- Bulb Lumens: 2200L-4600L
- Voltage: 100V-277V
- CCT: 3500K/4000K/5000K Selectable
- Integrated emergency battery backup with 90-minute run time
- Flicker Free, Even Light Distribution
- 0-10V Dimmable
- 50,000 average rated hours of use
- DLC Listed
- Title 20 Compliant
- Dimmable: True
- Sensor: No Photocell
- Assembly Required: Yes
- Safety Rating: CETLUS Listed
- For Use in Damp Locations
- Warranty Info: 5 Year Limited - Fixtures
- Overall Dimensions: 47.72"(L) x 11.84"(W) x 3.09"(H)
- Item Weight: 4.98 lbs.
Frequently asked
Is the bulb included? Yes, integrated LED - no bulb replacement needed.
Is it dimmable, and what dimmer should I use? Yes, dimmable via 0-10V dimmer (not included). Use a compatible 0-10V dimmer switch.
Can I install this in a bathroom or outdoors? It is rated for damp locations, so it can be used in bathrooms (not directly in shower) or covered patios, but not in wet locations.
What's the warranty? 5-year limited warranty on the fixture.
How do I select the wattage and color temperature? Use the ColorQuick and PowerQuick switches on the fixture to choose between 20W/30W/40W and 3500K/4000K/5000K before installation.
