A field-selectable LED high bay fixture for commercial and industrial spaces like warehouses, garages, and workshops, offering adjustable wattage (80W/100W/120W) and color temperature (3000K/4000K/5000K) to suit different lighting needs.
The Nuvo Lighting 65-812 Round High Bay is a versatile, energy-efficient replacement for traditional HID fixtures. Its durable die-cast aluminum housing and IK08 impact-rated polycarbonate lens withstand harsh environments. With 6kV surge protection, 120V-347V range voltage, and NEMA 4X (IP65) wet location rating, it's built for reliability in demanding commercial settings. The integrated LED provides up to 18,600 lumens with a 50,000-hour lifespan, and 0-10V dimming allows fine-tuning brightness.
Best for
- Warehouses and distribution centers with ceiling heights 15-25 ft, providing bright, uniform light for aisles and storage areas
- Garages and auto shops where adjustable color temperature helps with detailed work
- Manufacturing facilities requiring durable, impact-resistant lighting
- Covered outdoor areas and wet locations such as loading docks or parking garages
- Retail spaces with high ceilings needing energy-efficient, long-lasting illumination
Not ideal for
- Residential living spaces - the high lumen output and industrial design are overpowering for home rooms
- Low ceilings under 10 ft - the fixture's size and brightness are designed for higher mounting
- Decorative or hospitality settings where aesthetics are a priority
How bright is it?
Selectable from 11,840 to 18,600 lumens - comparable to a 250W-400W metal halide fixture. At the highest setting, it can illuminate a 20x20 ft area to warehouse-grade brightness. The 0-10V dimming allows reduction down to 10% for lower light needs.
Light color and feel
Field-selectable among 3000K (warm white, cozy), 4000K (neutral white, crisp), and 5000K (daylight, energizing). 80 CRI provides adequate color rendering for most industrial tasks. The ability to choose CCT during installation lets you match the lighting to the specific task or ambiance.
Sizing and fit
Compact round design: 11 inches diameter, 7.3 inches height. Weighs 4.53 lbs. Suitable for ceiling heights from 10 to 25 ft. The included 6-foot supply whip and low-voltage whip simplify installation. Compatible with optional accessories (sold separately) for mounting flexibility.
Specifications
- Finish: White
- Style: Utility
- Bulb Color Temp: 3000K/4000K/5000K
- Bulb Wattage: 80W/100W/120W
- Bulb Average Hours: 50000
- Bulb Lumens: 11840L-18600L
- Bulb Shape: Integrated LED
- Bulb CRI: 80
- Voltage: 120V-347V
- Bulb Included: Integrated
- Lamp Base: Integrated
- Sensor: Optional Add-On
- Color Temperature: Warm White to Natural Light
- CCT and Wattage Selectable
- Range Voltage 120V-347V
- Integrated Sensor Port
- 6 Foot Supply and Low Voltage Whips
- 0-10V Dimming
- 6kV Surge Protection and Wet Location Rated
- IP65 and IK08
- 50,000 Hour Functional Life
- White Finish
- 0-10V Dimming Only
- Dimmable: Yes-Dimmable
- Assembly Required: Yes
- For Use in Wet Locations
- Safety Rating: CULUS - Certified
- Warranty Info: 5 Year Limited - Fixtures
- Overall Dimensions: 11"(D) x 11"(W) x 7.3"(H)
- Item Weight: 4.53 lbs.
Frequently asked
Is the bulb included? Yes, the LED is integrated and included.
Is it dimmable, and what dimmer should I use? Yes, dimmable via 0-10V dimming (requires compatible 0-10V dimmer, not included).
Can I install this in a bathroom or outdoors? Yes, it is rated for wet locations (NEMA 4X/IP65), suitable for covered outdoor areas and damp environments.
What's the warranty? 5-year limited warranty on the fixture.
How do I select the wattage and color temperature? The fixture has a small switch on the side that lets you choose between 80W/100W/120W and 3000K/4000K/5000K before installation.
