A field-selectable 11-inch round LED high bay for warehouses, workshops, and commercial spaces, finished in black with durable die-cast aluminum housing.
SATCO|NUVO's 65-770R3 Round High Bay offers an energy-efficient and low-maintenance alternative to traditional HID fixtures. This luminary is field selectable, giving users the flexibility to choose from three wattage (80W/100W/120W) and three CCT options (3000K/4000K/5000K) during installation. Constructed with a durable die-cast aluminum housing and an IK08 impact-rated polycarbonate lens, it features 6kV surge protection, 120V-347V range voltage, and NEMA 4X (IP65) wet location ratings, making it resilient in various commercial environments.
Best for
- Warehouses and distribution centers with ceiling heights 15-30 ft, providing bright, uniform light for aisles and storage areas
- Commercial workshops and manufacturing floors where impact resistance and wet location ratings are needed
- Retail big-box stores and gymnasiums requiring adjustable brightness and color temperature
- Garages and covered parking structures with 120V-347V electrical systems
- Cold storage or damp environments thanks to IP65 wet location rating
Not ideal for
- Residential living rooms or bedrooms - this is a commercial-grade fixture designed for high ceilings and industrial use
- Spaces with ceilings under 10 ft - the light distribution may be too intense
- Applications requiring a decorative aesthetic - the utility style is purely functional
How bright is it?
Selectable from 11,840 to 18,600 lumens depending on wattage setting. At 120W/18,600 lumens, it's comparable to a 400W metal halide fixture, suitable for illuminating large areas. At 80W/11,840 lumens, it's similar to a 250W HID, ideal for lower ceilings or task areas.
Light color and feel
Field selectable between 3000K (warm white), 4000K (neutral white), and 5000K (daylight). 3000K provides a cozy, inviting glow; 4000K is crisp and clean for task-oriented spaces; 5000K simulates daylight for maximum visibility. CRI 80 ensures adequate color rendering for most commercial tasks. Dimmable via 0-10V dimming for energy savings and ambiance control.
Sizing and fit
Compact 11-inch diameter and 7.3-inch height, weighing 4.53 lbs. Ideal for mounting on ceilings 15-30 ft high. The 6-foot supply and low voltage whips provide flexibility in installation. Compatible with a wide variety of accessories (sold separately) for customization.
Specifications
- Finish: Black
- Style: Utility
- Bulb Color Temp: 3000K/4000K/5000K
- Bulb Wattage: 80W/100W/120W
- Bulb Average Hours: 50000
- Bulb Lumens: 11840L-18600L
- Bulb Shape: Integrated LED
- Bulb CRI: 80
- Voltage: 120V-347V
- Bulb Included: Integrated
- Lamp Base: Integrated
- Sensor: Optional Add-On
- Color Temperature: Warm White to Natural Light
- CCT and Wattage Selectable
- Range Voltage 120V-347V
- Integrated Sensor Port
- 6 Foot Supply and Low Voltage Whips
- 0-10V Dimming
- 6kV Surge Protection and Wet Location Rated
- IP65 and IK08
- 50,000 Hour Functional Life
- Black Finish
- 0-10V Dimming Only
- Dimmable: Yes-Dimmable
- Assembly Required: Yes
- For Use in Wet Locations
- Safety Rating: CULUS - Certified
- Warranty Info: 5 Year Limited - Fixtures
- Overall Dimensions: 11"(D) x 11"(W) x 7.3"(H)
- Item Weight: 4.53 lbs.
Frequently asked
Is the bulb included? Yes, the LED is integrated and not replaceable.
Is it dimmable, and what dimmer should I use? Yes, it is dimmable via 0-10V dimming (low voltage control). Use a compatible 0-10V dimmer switch.
Can I install this in a bathroom or outdoors? Yes, it is rated for wet locations (IP65) and can be used in covered outdoor areas, bathrooms, or damp environments.
What's the warranty? 5-year limited warranty on the fixture.
How do I select the wattage and color temperature? The fixture has a small switch inside that allows you to choose between 80W, 100W, or 120W and 3000K, 4000K, or 5000K before installation.
