A versatile ceiling fan motor from Fanimation's Wrap Custom collection, finished in satin brass, for living rooms and covered patios.
The Wrap Custom motor is the heart of a customizable ceiling fan system. Choose your blade finish and optional light kit to match your decor. The DC motor is energy-efficient and reversible for year-round comfort. This motor is damp-rated, making it suitable for indoor or covered outdoor spaces. It includes a TR305 handheld remote and is ENERGY STAR Most Efficient 2022.
Best for
- Living rooms and great rooms with 44-60 inch ceilings, paired with blades of your choice
- Covered patios and porches, thanks to its damp rating
- Bedrooms and home offices where quiet, energy-efficient airflow is desired
- Homes with smart systems, as it is WiFi compatible via the fanSync app
- Multi-season use with reversible airflow
Not ideal for
- Spaces where a light kit is required, as the light kit is sold separately
- Areas with direct water exposure, as it is damp-rated, not wet-rated
- Low ceilings under 8 feet if you prefer a flush mount, as this includes a 4.5-inch downrod
How bright is it?
This is a ceiling fan motor only; brightness depends on the optional LED light kit, which is sold separately. Lumen output is not specified by the manufacturer.
Light color and feel
Light color and feel depend on the optional LED light kit, which is sold separately. The fan motor itself does not emit light.
Sizing and fit
The motor is designed to fit blades from 44 to 60 inches in diameter. The overall height is 12.46 inches, and the canopy is 6.14 inches in diameter. The included 4.5-inch downrod suits standard 8-9 foot ceilings; longer downrods may be needed for higher ceilings.
Specifications
- Part of the Wrap Custom Collection
- Finish: Brushed Satin Brass
- Voltage: 120V
- DC motor with reverse switch, variable speeds, light controls, sleep timer, home away, fresh air and safe exit features
- Compatible with smart home devices using the Wi-Fi fanSync app
- ENERGY STAR Most Efficient 2022
- TR305 handheld remote with 23A battery included
- Maximum Slope Degree: 27
- Reverse Switch Location: Control
- Motor Type: DC
- Motor Size: 158 X 22
- Length of Electrical Wire: 80"
- Number Of Blades: 3
- Blade Pitch: Varied
- Downrod Length: 4.5
- Number Of Speeds: 16
- Safety Rating: UL/cUL Listed
- For Use in Damp Locations
- Warranty Info: Limited Lifetime Warranty
Frequently asked
Is the bulb included? No, this is a fan motor only. The optional LED light kit is sold separately.
Is it dimmable, and what dimmer should I use? Dimmability depends on the light kit and controls. The fan motor has variable speeds controlled by the included remote or app.
Can I install this in a bathroom or outdoors? It is damp-rated, so it can be used in covered outdoor areas and bathrooms with adequate ventilation, but not in direct water exposure.
What's the warranty? Limited Lifetime Warranty.
What blade finishes are available? Multiple blade finishes are available and sold separately. Check the Fanimation website for options.
