A 54-inch downrod smart ceiling fan with an integrated LED light kit, finished in brushed nickel with dark walnut blades, for covered patios, sunrooms, and large rooms.
The Spitfire DC Custom combines powerful airflow with customizable lighting. Its 6-speed DC motor delivers up to 7,307 CFM, and the included 18-watt LED light kit offers five color temperatures from warm to daylight. The brushed nickel finish and dark walnut blades create a modern, natural look. Wi-Fi enabled fanSync technology allows control via smart device or voice assistant, and the included TR360 remote provides convenient handheld control.
Best for
- Covered patios and porches, where the damp-rated construction stands up to humidity without direct rain exposure
- Sunrooms and three-season rooms that need both airflow and adjustable lighting
- Living rooms and great rooms with ceilings 8 feet or higher, using the included downrods to achieve optimal height
- Bedrooms where you want a fan with a light kit for ambient illumination
- Smart-home setups, with Wi-Fi control via the fanSync app and voice assistants
Not ideal for
- Outdoor areas directly exposed to rain or water—this fan is damp-rated, not wet-rated
- Rooms with very low ceilings (under 8 feet) where a downrod mount may reduce headroom—consider the flush-mount version
- Very large open-concept spaces over 400 square feet, where a single 54-inch fan may not provide enough airflow
How bright is it?
The integrated 18-watt LED light kit produces 1,600 lumens—about as bright as a 100W incandescent bulb. This is suitable for ambient lighting in a bedroom or living area, but not as a primary task light for detailed work.
Light color and feel
You can choose from five color temperatures: 2700K (warm white), 3000K (soft white), 3500K (neutral), 4000K (cool white), and 5000K (daylight). This lets you shift from a cozy, golden glow to crisp, bright light. With a CRI of 90, colors appear accurate and vibrant.
Sizing and fit
This downrod fan measures 54 inches in blade sweep and hangs 19.42 inches from the ceiling with the included 6-inch downrod. It also includes a 12-inch downrod, and optional downrods up to 72 inches are available to achieve the recommended 7-9 foot hanging height. The canopy is 7.85 inches in diameter, and the housing is 8.07 inches. It weighs 19.23 pounds and is designed for flat or slightly sloped ceilings (up to 20°).
Specifications
- Primary Finish: Brushed Nickel
- Blade Material: Buttonwood
- Blade Finish: Dark Walnut
- Shade Finish: Fresnel and Frosted
- Collection: Spitfire
- Blade Sweep: 54"
- Number of Blades: 3
- Blade Pitch: 21°
- Motor Type: DC
- Motor Size: 153 X 22
- Motor Reversible: True
- Number of Speeds: 6
- Reverse Switch Location: Control
- Light Kit Included: True
- Cap Included: True
- Included Control: TR360
- Control Type: Handheld
- 1 Bulb(s)
- Bulb Type: LED Module
- Bulb Base: Connector Pin
- Bulb Max Wattage: 18W
- Color Temperature: 2700, 3000, 3500, 4000, 5000K
- CRI: 90
- Lumens: 1600
- Voltage: 120V
- Avg CFM: 4157
- CFM High: 7307
- Avg Energy Use: 18W
- Max Slope: 20°
- Location Rating: Damp
- Safety Rating: UL Only Listed
- Warranty: Limited Lifetime Warranty
- Overall Dimensions: 54"(L) x 54"(W) x 19.42"(H)
- Housing Diameter: 8.07"
- Canopy Dimensions: 7.85"(Dia) x 5.02"(H)
- Downrod Length: 6, 12"
- Leadwire Length: 14 motor & 15 light"
- Ceiling to Bottom (No Light Kit): 13.69, 19.69"
- Ceiling to Bottom (With Light Kit): 15.35, 21.35"
- Item Weight: 19.23 lbs.
Frequently asked
Is the bulb included? Yes, the integrated LED light kit is included and features a non-replaceable LED module.
Is it dimmable, and what dimmer should I use? The light is dimmable via the included TR360 remote or the fanSync app. The fan speed is also adjustable through the remote.
Can I install this in a bathroom or outdoors? Yes, this fan is damp-rated, so it's safe for bathrooms and covered outdoor areas like patios and porches. It should not be directly exposed to rain or water.
What's the warranty? Fanimation offers a Limited Lifetime Warranty for the original purchaser, covering the motor. Contact Fanimation Tech Support at 1-888-567-2055 for assistance.
Does this fan work with sloped ceilings? Yes, it is designed for flat or slightly sloped ceilings up to 20°. For steeper slopes, you may need a sloped ceiling adapter (sold separately).
