A 96-inch downrod smart ceiling fan with integrated LED light kit from Fanimation's Spitfire collection, finished in black with matte white blades, for large covered outdoor and indoor spaces.
The Spitfire DC Custom with light kit brings powerful airflow and customizable lighting to expansive rooms and covered patios. Its 96-inch blade sweep and three matte white buttonwood blades deliver up to 12,413 CFM, while the integrated 18-watt LED light kit offers five color temperatures from warm to daylight. The included TR360 remote and Wi-Fi fanSync app provide full control over fan speed, light dimming, and CCT selection. Damp-rated for covered outdoor use, it's built to handle humidity without direct rain exposure.
Best for
- Covered patios and porches 20x20 ft or larger, where its 96-inch sweep moves air across the whole seating area
- Sunrooms and three-season rooms with high ceilings, using the included 6-inch or 12-inch downrods
- Great rooms and open-plan living areas with ceilings 10 ft or higher
- Bathrooms and laundry rooms with high ceilings, where damp-rated construction resists humidity
Not ideal for
- Small rooms under 12x12 ft - the 96-inch blade sweep will overpower the space
- Outdoor areas directly exposed to rain or water - this fan is damp-rated, not wet-rated
- Rooms with ceilings under 8 ft, as the downrod adds height
How bright is it?
The integrated 18-watt LED light kit provides 1600 lumens - about as bright as a 100W incandescent bulb - suitable for ambient lighting in large rooms.
Light color and feel
You can select from five color temperatures: 2700K (warm white), 3000K (soft white), 3500K (neutral), 4000K (cool white), and 5000K (daylight). This flexibility lets you match the light to your activity and mood. The kit also features a CRI of 90, rendering colors accurately.
Sizing and fit
This downrod fan measures 96 inches in diameter and 19.42 inches from ceiling to bottom with the included 12-inch downrod. It's designed for flat or slightly sloped ceilings (up to 20°). Optional downrods up to 72 inches are available for higher ceilings.
Specifications
- Primary Finish: Black
- Blade Material: Buttonwood
- Blade Finish: Matte White
- Shade Finish: Fresnel and Frosted
- Collection: Spitfire
- Blade Sweep: 96"
- Number of Blades: 3
- Blade Pitch: 14°
- Motor Type: DC
- Motor Size: 153 X 22
- Motor Reversible: True
- Number of Speeds: 6
- Reverse Switch Location: Control
- Light Kit Included: True
- Cap Included: True
- Included Control: TR360
- Control Type: Handheld
- 1 Bulb(s)
- Bulb Type: LED Module
- Bulb Base: Connector Pin
- Bulb Max Wattage: 18W
- Color Temperature: 2700, 3000, 3500, 4000, 5000K
- CRI: 90
- Lumens: 1600
- Voltage: 120V
- Avg CFM: 8515
- CFM High: 12413
- Avg Energy Use: 24W
- Max Slope: 20°
- Location Rating: Damp
- Safety Rating: UL Only Listed
- Warranty: Limited Lifetime Warranty
- Overall Dimensions: 96"(L) x 96"(W) x 19.42"(H)
- Housing Diameter: 8.07"
- Canopy Dimensions: 8.76"(Dia) x 2.52"(H)
- Downrod Length: 6, 12"
- Leadwire Length: 14 motor & 15 light"
- Ceiling to Bottom (No Light Kit): 13.69, 19.69"
- Ceiling to Bottom (With Light Kit): 15.35, 21.35"
- Item Weight: 22.25 lbs.
Frequently asked
Is the bulb included? Yes, the integrated LED light kit is included and the LED module is built-in.
Is it dimmable, and what dimmer should I use? The light kit is dimmable via the included TR360 remote. No wall dimmer is required.
Can I install this in a bathroom or outdoors? Yes, it is damp-rated for indoor and covered outdoor spaces, including bathrooms and covered patios. It should not be directly exposed to rain or water.
What's the warranty? Fanimation offers a Limited Lifetime Warranty for the original purchaser.
How do I control the fan and light? The included TR360 handheld remote controls fan speed, light dimming, and CCT selection. Wi-Fi fanSync allows control via smart device or voice assistant.
