A 64-inch smart ceiling fan with an integrated LED light kit, designed for both indoor and outdoor wet-rated spaces like patios and pergolas.
The Odyn Custom by Fanimation commands attention with its bold, modern design. The brushed nickel motor housing pairs with nine black composite blades for a striking, contemporary look that suits a variety of decor styles. Its DC motor is energy-efficient, using up to 70% less energy than traditional motors, and the integrated LED light kit offers selectable color temperatures to match your mood.
Best for
- Covered patios, pergolas, and porches where wet-rated durability is essential
- Great rooms and open-plan living areas with high ceilings, using the included 12-inch downrod or optional longer downrods
- Bedrooms and living rooms that benefit from quiet, energy-efficient airflow with smart control
- Spaces where you want both a fan and a dimmable light source in one fixture
- Homes with smart assistants like Alexa or Google Home for voice control via the fanSync app
Not ideal for
- Rooms with ceilings under 8 feet, as the fan hangs 22.63 inches from the ceiling and may be too low
- Small rooms under 150 square feet, where the 64-inch blade sweep may be overpowering
- Those who prefer a traditional or ornate fan style, as the Odyn has a sleek, modern aesthetic
How bright is it?
The integrated LED module produces 1600 lumens, comparable to a 100-watt incandescent bulb. This is bright enough to serve as a primary light source in a medium-sized room, and it's dimmable to create a softer ambiance when needed.
Light color and feel
With CCT Select technology, you can choose from 3000K warm white, 4000K bright white, or 5000K daylight. This flexibility lets you tailor the light to the activity and time of day. The high CRI of 90 ensures colors appear vivid and accurate, ideal for spaces where you want true-to-life lighting.
Sizing and fit
The fan has a 64-inch blade sweep and overall dimensions of 64 inches wide by 64 inches deep by 22.63 inches high. It comes with a 12-inch downrod, and optional downrods up to 72 inches are available to achieve the recommended 7-9 foot hanging height. Suitable for flat or sloped ceilings up to 27 degrees.
Specifications
- Primary Finish: Brushed Nickel
- Blade Material: Composite
- Blade Finish: Black
- Shade Finish: Opal Frosted
- Collection: Odyn Custom
- Blade Sweep: 64"
- Number of Blades: 9
- Blade Pitch: 12°
- Motor Type: DC
- Motor Size: 135
- Motor Reversible: True
- Number of Speeds: 16
- Reverse Switch Location: Control
- Light Kit Included: True
- Cap Included: True
- Included Control: TR305
- Control Type: Handheld
- 1 Bulb(s)
- Bulb Type: LED Module
- Bulb Base: Connector Pin
- Bulb Max Wattage: 18W
- Color Temperature: 3000/4000/5000K
- CRI: 90
- Lumens: 1600
- Voltage: 120V
- Avg CFM: 4934
- CFM High: 8415
- Avg Energy Use: 22W
- Max Slope: 27°
- Location Rating: Wet
- Safety Rating: UL/cUL Listed
- Energy Star: True
- Warranty: Limited Lifetime Warranty
Frequently asked
Is the bulb included? Yes, the integrated LED module is included and cannot be replaced.
Is it dimmable, and what dimmer should I use? Yes, the light is dimmable via the included TR305 remote or the fanSync app. No separate wall dimmer is required.
Can I install this in a bathroom or outdoors? Yes, it is wet-rated, so it can be installed in wet locations like covered patios, pergolas, and porches, as well as bathrooms with adequate clearance.
What's the warranty? Limited Lifetime Warranty for the original purchaser, covering the motor. For assistance, contact Fanimation Tech Support at 1-888-567-2055.
Can I control the fan with my voice? Yes, the fanSync app works with Amazon Alexa and Google Assistant for voice control.
