A compact 4W LED puck light for under-cabinet task lighting and display accent, finished in white with a frosted polycarbonate diffuser.
The Dainolite PLED-04-WH is a low-profile LED puck light designed for under-cabinet installation in kitchens, workshops, and display cases. Its white powder-coated metal housing and frosted diffuser blend seamlessly into modern interiors. Powered by a 24VDC input (driver not included), this fixture delivers focused task light with a 40° beam spread.
Best for
- Under-cabinet task lighting in kitchens, illuminating countertops for food prep
- Display case or shelf accent lighting in living rooms or retail settings
- Workshop or utility area task lighting where a compact, low-heat source is needed
Not ideal for
- General room ambient lighting - the 40° beam is too narrow to light a whole room
- Outdoor or damp locations - rated for indoor use only
How bright is it?
314 lumens - comparable to a 25W incandescent bulb, ideal for task lighting over a counter or inside a cabinet. Not bright enough to serve as a primary room light.
Light color and feel
3000K warm white - a soft, golden tone similar to traditional incandescent lighting. CRI 80+ provides decent color rendering for most tasks. Dimmable with a compatible PWM dimmer (recommended: DVELV-300P).
Sizing and fit
Each puck measures 2.64 inches in diameter and just 0.61 inches tall, making it easy to mount under standard cabinets. The 18-inch white cord connects via male connector to a 24VDC driver (sold separately).
Specifications
- Finish: White
- Primary Made of Metal
- Primary Type of Finish: Powder Coating
- (1) 4W LED Bulb(s)
- Bulb(s) Included
- Bulb 1 Color Temp: 3000K
- Bulb 1 Lumens: 314lm
- Bulb 1 Beam Spread: 40°
- Bulb 1 CRI: > 80
- Trim Size: 2.64"
- Install Position: Under Cabinet
- Diffuser Made of Polycarbonate
- Diffuser Color: Frosted
- Dimmer Type: PWM
- Dimmer Included: No
- Recommended Dimmer: DVELV-300P
- Connection Type: Male Connector
- Length of Electrical Cord: 18"
- Color of Electrical Cord: White
- Number of Transformers/Drivers: 1
- Transformer/Driver Included: No
- Type of Transformer/Driver: LED Driver
- Transformer/Driver Wattage: 24V DC Max 96W
- Voltage: 24VDC
- Dimmable: Yes
- For Indoor Use
- Warranty Info: 5 Years
- Overall Dimensions: 0.61"(L) x 2.64"(W) x 0.61"(H)
- Item Weight: 0.18 lbs.
Frequently asked
Is the bulb included? Yes, the LED bulb is integrated and included.
Is it dimmable, and what dimmer should I use? Yes, it is dimmable with a PWM dimmer. The recommended dimmer is DVELV-300P.
Can I install this in a bathroom or outdoors? No, this puck light is rated for indoor use only.
What's the warranty? 5 years.
Do I need a separate driver? Yes, a 24VDC LED driver is required but not included. The driver wattage should be at least 96W total for multiple pucks.
